Output and consumption |
|
VALUE |
Energy consumption in 24h |
|
1.067 kWh / 24h |
Measurement methodology for energy consumption
|
|
Empty measurement +5 °C / -20 °C / ambient temperature +25 °C
|
Noise level |
|
48 dB |
Energy consumption per year |
|
390 kWh/a |
Ambient temperature |
|
+10 °C to 35 °C |
Refrigerant |
|
R 600a |
Heat emission |
|
350 kJ/h |
Heat distribution system |
|
Air cooling |
Rated power consumption Watt |
|
170.0 W |
Voltage |
|
220-240 V ~ |
Frequency |
|
50/60 Hz |
Control and functions |
|
VALUE |
Control unit |
|
Touch |
Power failure alarm |
|
when mains power returns |
Malfunction: Warning signal |
|
optical and acoustical |
positive temperature deviation from the setpoint
|
|
2.5 Kelvin |
negative temperature deviation from the setpoint
|
|
2.7 Kelvin |
Heating from +5 °C to +10 °C (empty, +25 °C TU)
|
|
80 min |
Heating from -20°C to -15°C (empty, +25°C TU)
|
|
45 min |
Cooling time from +25°C to +5°C (empty, +25°C TU)
|
|
35 min |
Cooling time from +25 °C to -20 °C (empty, +25 °C TU)
|
|
150 min |
Recovery time after 1 min door opening (empty, +25 °C TU, according to
EN 60068-3)
|
|
10 min |
potential-free contact |
|
✔ |
SmartMonitoring-enabled |
|
Yes |
Connectivity type |
|
SmartModule |
Interface |
|
WLAN/LAN (optional) |
min./max. temperature recording |
|
Yes |
Alarm history |
|
No |
Product sensor |
|
No |
Refrigerator compartment |
|
VALUE |
Gross volume cooling |
|
267 L |
Net volume cooling |
|
199 L |
Adjustable temperature range |
|
+3°C to +16 °C |
Temperature display |
|
external digital |
Cooling system, refrigerator compartment
|
|
dynamic |
Defrosting method |
|
automatic |
Interior light |
|
- |
Number of storage shelves |
|
5 |
of which adjustable
|
|
4 |
Bottom grid shelf |
|
- |
Freezer compartment |
|
VALUE |
Gross volume freezing |
|
110 L |
Net volume freezing |
|
62 L |
Adjustable temperature range |
|
-9 °C to -30 °C |
Temperature display |
|
external digital |
Cooling technology |
|
SmartFrost |
Cooling system, freezer compartment |
|
static |
Defrosting method |
|
manual |
Interior light |
|
- |
Drawers in freezer compartment |
|
3 |
Number of storage shelves |
|
3 |
of which adjustable |
|
0 |
Bottom grid shelf |
|
- |
Design and materials |
|
VALUE |
Side wall material |
|
Steel |
Color |
|
White |
Door material |
|
Full-panel door |
Handle |
|
Antimicrobial handle with opening mechanism |
Material of interior containers |
|
Plastic white |
Storage shelf material, refrigerator compartment
|
|
Glass |
Material of adjustable shelves in the freezer compartment
|
|
Glass |
Material of adjustable feet |
|
Steel, zinced |
Setup and installation |
|
VALUE |
Self-closing door |
|
✔ |
Door hinges |
|
Right |
Door hinge replacement |
|
Possible for customer |
Door seal |
|
Replaceable |
Height-adjustable feet |
|
— mm |
Castors |
|
- |
Type of castors |
|
- |
Type of lock |
|
mechanical |
Max. height of the installation site
|
|
2,000 m above sea level |
Connector cable (length) |
|
3,000 mm |
Specifications |
|
VALUE |
Total gross volume |
|
377 L |
Total net volume |
|
261 L |
Exterior dimensions: height/width/depth |
|
204.4 / 59.7 / 65.4 cm |
Exterior dimensions: height/width/depth (with packaging)
|
|
2,080.0 / 615.0 / 725.0 mm |
Weight (without packaging) |
|
83.00 kg |
Weight (with packaging) |
|
89 kg |
Load-bearing capacity of shelf areas, refrigerator compartment
|
|
40 kg |
Load-bearing capacity of shelf areas, freezer compartment
|
|
40 kg |
Net width of shelves |
|
46 cm |
net depth of storage shelves |
|
42.2 cm |
Certifications |
|
IEC 60068-3 / IEC 60079-0 / IEC 60079-7 / IEC 61010-1 / IEC 61010-2-011
/ IEC 61326-1
|
ATEX classification |
|
< Ex > II 3/- G Ex ec IIC T6 Gc/- |
Clean room class according to ISO EN 14664-1
|
|
ISO class 5 |
